MSP430F149IPMR 16-Bit 8MHz 60KB MSP430 series Microcontroller IC Texas Instruments MCU

Category:
Microcontroller IC
Price:
Negotiated
Payment Method:
T/T, Western Union
Specifications
Products Name:
Integrated Circuits(IC)
Details:
MSP430 Series Microcontroller IC 16-Bit 8MHz 60KB (60K X 8 + 256B) FLASH 64-LQFP (10x10)
Category:
Electronic Components
IC Family:
MSP430 Series MCU
Other Name:
MSP430F149IPM MSP430
Package:
64-LQFP (10x10)
Description:
IC MCU 16BIT 60KB FLASH 64LQFP
Base Part Number:
430F149
Lead Free Status:
RoHS Compliant, PB Free, Lead Free
Related Parts:
MSP430F149 MSP430F148 MSP430F147 MSP430F1491 MSP430F1481 MSP430F1471 MSP430F135 MSP430F133
Introduction

MSP430F149IPMR 16-Bit 8MHz 60KB MSP430 series Microcontroller IC Texas Instruments MCU



MSP430F149 MSP430F148 MSP430F147 MSP430F1491 MSP430F1481 MSP430F1471
MSP430F135 MSP430F133  MSP430 series Microcontroller IC 16-Bit 8MHz 60KB (60K x 8 + 256B) FLASH 64-LQFP (10x10)



Description:

The Texas Instruments MSP430 family of ultra-low-power microcontrollers (MCUs) consist of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low-power modes is optimized to achieve extended battery life in portable measurement applications. The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that attribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 6 µs. The MSP430F13x, MSP430F14x, and MSP430F14x1 MCUs support two built-in 16-bit timers, a fast 12-bit ADC on the MSP430F13x and the MSP430F14x devices, one USART on the MSP430F13x devices or two USARTs on the MSP430F14x and MSP430F14x1 devices, and 48 I/O pins. The hardware multiplier enhances the performance and offers a broad code and hardware-compatible family solution.



Features:

• Industry-leading ultra-low power consumption – 5-Hz version: 0.54 µA with 1.8 V – 20-Hz versions: 1.6 µA with 3 V • 1.65-V to 5.5-V operating VCC range • Magnetic threshold options (maximum BOP): – 3.9 mT, highest sensitivity – 4.8 mT, high sensitivity – 9.5 mT, medium sensitivity – 63 mT, lowest sensitivity • Omnipolar and unipolar options • 20-Hz and 5-Hz sampling rate options • Open-drain and push-pull output options • SOT-23, X2SON and TO-92 package options • –40°C to +85°C operating temperature range.



Applications:

Sensor Systems

Industrial Controls

Hand-Held Meters





Features:

• Low Supply Voltage Range, 1.8 V to 3.6 V

• Ultra-Low Power Consumption: – Active Mode: 280 µA at 1 MHz, 2.2 V – Standby Mode: 1.6 µA – Off Mode (RAM Retention): 0.1 µA

• Five Power-Saving Modes • Wakeup From Standby Mode in Less Than 6 µs • 16-Bit RISC Architecture, 125-ns Instruction Cycle Time

• 12-Bit Analog-to-Digital Converter (ADC) With Internal Reference, Sample-and-Hold, and Autoscan Feature

• 16-Bit Timer_B With Seven Capture/CompareWith-Shadow Registers

• 16-Bit Timer_A With Three Capture/Compare Registers • On-Chip Comparator

• Serial Onboard Programming, No External Programming Voltage Needed, Programmable Code Protection by Security Fuse.

Serial Communication Interface (USART),

Functions as Asynchronous UART or Synchronous SPI Interface – Two USARTs (USART0, USART1)

On MSP430F14x and MSP430F14x1 Devices – One USART (USART0) On MSP430F13x Devices

• Family Members (Also See Device Comparison)

– MSP430F133 – 8KB + 256 Bytes of Flash Memory, 256 Bytes of RAM

– MSP430F135 – 16KB + 256 Bytes of Flash Memory, 512 Bytes of RAM

– MSP430F147, MSP430F1471 – 32KB + 256 Bytes of Flash Memory, 1KB of RAM

– MSP430F148, MSP430F1481 – 48KB + 256 Bytes of Flash Memory, 2KB of RAM

– MSP430F149, MSP430F1491 – 60KB + 256 Bytes of Flash Memory, 2KB of RAM



IC MCU 16BIT 60KB FLASH 64LQFP Specifications:

Category
Integrated Circuits (ICs)

Embedded - Microcontroller IC
Mfr
Texas Instruments
Series
MSP430x1xx
Package
Tape & Reel (TR)
Part Status
Active
Core Processor
MSP430
Core Size
16-Bit
Speed
8MHz
Connectivity
SPI, UART/USART
Peripherals
POR, PWM, WDT
Number of I/O
48
Program Memory Size
60KB (60K x 8 + 256B)
Program Memory Type
FLASH
Part Number MSP430F149IPMR
RAM Size
2K x 8
Voltage - Supply (Vcc/Vdd)
1.8V ~ 3.6V
Data Converters
A/D 8x12b
Oscillator Type
Internal
Operating Temperature
-40°C ~ 85°C (TA)
Mounting Type
Surface Mount
Package / Case
64-LQFP
Supplier Device Package
64-LQFP (10x10)
Base Product Number
430F149





Device Information :

MSP430F149IPM       LQFP (64)    10 mm × 10 mm
MSP430F149IPAG    TQFP (64)     10 mm × 10 mm
MSP430F1491IRTD    VQFN (64)     9 mm × 9 mm



Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001



We committed to sell the full range of Texas Instuments integrated circuits.

For more information about related parts ,please feel free to email by sales@icschip.com



Similar products as follows for reference:



MSP430F149 MSP430F148 MSP430F147 MSP430F1491 MSP430F1481 MSP430F1471 MSP430F135 MSP430F133 MSP430 full series Microcontroller IC
