KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module

Product Details:
Place of Origin: CHINA
Brand Name: OEM
Certification: ROHS
Model Number: KCX_BT_EMITTER Audio Module Board
Payment & Shipping Terms:
Minimum Order Quantity: 10pieces
Price: US$4.25
Packaging Details: BOX
Delivery Time: 5-14days
Payment Terms: T/T, Western Union,paypal
Supply Ability: 5000pcs

Detail Information

Category: Development Boards, Kits, Programmers Product Name: KCX_BT_EMITTER Audio Module Board
Family: 4.1 Stereo Audio GFSK Transceiver Transmitter Wireless Speaker Headphones Board Type: Wifi Development Board
Series: KCX_BT_EMITTER Package: 1 Development Board/Bag
Description: KCX_BT_EMITTER Audio Module Board 4.1 Stereo Audio GFSK Transceiver Transmitter Wireless Speaker Headphones Condition: New And Original Sealed Package
High Light:

KCX_BT_EMITTER GFSK Transceiver

,

Bluetooth Audio Transmitter Module

,

KCX_BT_EMITTER

Product Description

KCX_BT_EMITTER Audio Module Board 4.1 Stereo Audio GFSK Transceiver Transmitter Wireless Speaker Headphones


1.Introduction:

KCX_BT_EMITTER module is a Blue-tooth audio transmitter module that integrates computer USB sound card to Blue-tooth transmission and line audio input and launch. It adopts Blue-tooth 4.1 technology to greatly ensure the quality and stability of audio transmission. This product can be used for most of the products. Blue-tooth transmitter function for desktop computers, notebook computers, TVs, projectors, game consoles, IPOD, CD players, MP3s, etc., to transmit audio signals to Blue-tooth audio receivers such as Bluetooth headsets or Bluetooth speakers to form a wireless audio transmission system. Let your life truly enter the wireless era!



2.Application:

2.1>.Wireless speaker
2.2>.Wireless audio
2.3>.Wireless headphones



3.Features:

3.1>.Easy to use
3.2>.Blue-tooth 4.1 technology, strong versatility
3.3>.Intuitive LED indication
3.4>.Line input stereo
3.5>.A USB data cable is connected to the computer and enumerated into a USB sound card to launch
3.6>.Wireless transmission distance >= 10 meters
3.7>.Perfectly compatible with all Blue-tooth audio receiver boards in this store
3.8>.The reserved serial communication port can be customized to realize the connection of the specified device name, specify the MAC address connection, search for the Bluetooth device name, MAC address, get the connection status, disconnect, etc., and configure the information to be powered off.
3.9>.Work voltage:5V



CategoryDevelopment Boards, Kits, Programmers
FamilyAudio Module Board
Product NameKCX_BT_EMITTER
Board TypeEvaluation Platform
Description4.1 Stereo Audio GFSK Transceiver Transmitter Wireless Speaker Headphones
After upgraded to KCX-BT-EMITTER V1.4It can be completely replaced with an external antenna
Utilized IC / PartACI813AP1E13
Mounting TypeFixed





KCX_BT_EMITTER V1.1 images (It has been upgraed to be KCX-BT-EMITTER V1.4 )

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 0

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 1

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 2

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 3



At present,KCX_BT_EMITTERV1.1 has been upgraded to be KCX_BT_EMITTERV1.4 as follows:

KCX_BT_EMITTERV1.4 can be completely replaced KCX_BT_EMITTERV1.1 with an external antenna.

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 4

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 5

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 6

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 7

KCX_BT_EMITTER GFSK Transceiver Bluetooth Audio Transmitter Module 8
