2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6
2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6

Product Details:
Place of Origin: JAPAN
Brand Name: JST (JAPAN SOLDERLESS TERMINALS)
Certification: ROHS
Model Number: BEH-001T-P0.6 SEH-001T-P0.6
Payment & Shipping Terms:
Minimum Order Quantity: 50pieces
Price: Negotiated
Packaging Details: Standard package
Delivery Time: 3-7days
Payment Terms: T/T, Western Union,paypal
Supply Ability: 50000PCS
Contact Now

Detail Information
Product Name: High Reliable 1.0 To 1.9mm Insulation Outer Diameter Category: Connectors, Interconnects-electrical Terminal Block Connectors
Family: EH Connector Applications: Mass Data Storage，High-end And Mid-range Servers，Telecommunications Equipment
Series: 2.5mm Pitch/disconnectable Crimp Style Votlage Rating: 250V AC, DC
For Use With/Related Products: 2.5mm Pitch/disconnectable Crimp Style Connectors Applicable For: 26 To 22AWG Wire
Base Product Number: BEH-001T-P0.6
High Light:

2.5mm Pitch JST EH Connectors

,

BEH-001T-P0.6

,

SEH-001T-P0.6

Product Description

BEH-001T-P0.6 SEH-001T-P0.6 High reliable EH Connector JST Terminal in Loose Form

2.5mm pitch/disconnectable crimp style



The BEH-001T-P0.6 is an EH Contact for use with 2.5mm pitch/disconnectable crimp style connectors. Phosphor bronze construction with tin-plated (reflow treatment) finish. Applicable for 26 to 22AWG wire



High reliable

Votlage rating: 250V AC, DC 1.0 to 1.9mm Insulation outer diameter



Specifications:

Part number BEH-001T-P0.6 SEH-001T-P0.6
Category
Connectors, Interconnects
　
Backplane Connectors - Accessories
Mfr
JST
Series
MultiGig
Package
Bag
Part Status
Active
Accessory Type
Guide Pin
For Use With/Related Products
MultiGig Series
Specifications
M5 Thread
Base Product Number
1469491

MULTIGIG RT Connector Products for VITA 46 (VPX) Standard for Mass data storage,High-end and mid-range servers,Telecommunications equipment



Environmental & Export Classifications



ATTRIBUTE DESCRIPTION
RoHS Status RoHS Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 0

Datasheet  for BEH-001T-P0.6 SEH-001T-P0.6 High reliable EH Connector

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 1

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 2

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 3

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 4

2.5mm Pitch JST EH Connectors Terminal BEH-001T-P0.6 SEH-001T-P0.6 5
