620mOhms 1W 2512 Smd Resistor RL2512JK-070R62L Electronic Resistor

Product Details:
Place of Origin: China
Brand Name: Uniohm ROYALOHM
Certification: ROHS
Model Number: RL2512JK-070R62L
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: US$1.00/100PCS
Packaging Details: Reel
Delivery Time: 3-8days
Payment Terms: T/T, Western Union
Supply Ability: 1000000/Month

Detail Information

Product Name: 620 MOhms ±5% 1W Chip Resistor 2512 (6432 Metric) Automotive AEC-Q200, Current Sense, Moisture Resistant Thick Film Applications: Consumer Electronics Automotive Electronics LED Lighting
Category: Passive Components-Passive Components Family: Moisture Resistant Thick Film Resistors
Operating Temperature: -55°C ~ 125°C Package Temperature: Tape & Reel (TR)
Mounting Type: Surface Mount, MLCC Tolerance: ±5%
Power: 1W Dimensions: 2512 SMD
High Light:

620mOhms 1W 2512 Smd Resistor

,

RL2512JK-070R62L

,

070R62L Electronic Resistor

Product Description

RL2512JK-070R62L 620 mOhms ±5% 1W Chip Resistor   (6432 Metric) Automotive AEC-Q200, Current Sense, Moisture Resis



RL2512JK-070R62L 620 mOhms ±5% 1W Chip Resistor 2512 (6432 Metric) Automotive AEC-Q200, Current Sense, Moisture Resis



Features:

Category
Resistors

Chip Resistor - Surface Mount
Mfr
 Electronic Components
Series
CHIP TYPE
Package
Tape & Reel (TR)
Part Status
Active
Resistance
620mOhms
Tolerance
±5%
Power (Watts)
1W
Composition
Thick Film
Features
Automotive AEC-Q200
Temperature Coefficient
±200ppm/°C
Operating Temperature
-55°C ~ 155°C
Supplier Device Package
smd2512
Ratings
AEC-Q200
Number of Terminations
2
Failure Rate
-
Base Product Number
RL2512JK-070R62L





Similar products:
