Product Description
Renesas' General Purpose power management ICs (PMIC chip)
Applications:
Consumer Electronics ICsProcessor Core Power, PMIC, Battery Chargers, Switching Regulators, LDOs, LED Backlight Drivers,
TFT-LCD DC-DC Regulators, Light Sensors
NOTEBOOK PC, TABLET, SMART PHONE, SMART WATCH, PORTABLE POWER TOOLS, E-BIKE, GAME CONSOLE,
DIGITAL STILL CAMERA, PICO PROJECTOR, LCD-TV PANEL
Available part numbers:
ISL29501,ISL9021A,ISL9111 ISL9111A,ISL91127 ISL91128,ISL9113 ISL9113A,ISL91132 ISL91133 ISL91134,ISL9120,ISL9230,ISL9238,ISL95852,ISL95855 ISL95857,ISL95908,ISL9590x,ISL98608,ISL98611 ISL98611A,ISL98611,ISL98611A
Overviews:
Renesas' power management ICs (PMICs) are integrated circuits that perform various functions related to the power requirements of a host system. A PMIC may have a combination of the following functions: DC/DC conversion, battery charging, linear regulation, power sequencing, and other miscellaneous system power functions.
Renesas' PMIC portfolio includes shunt regulators, point-of-load (POL) converters, ICs for power factor correction (PFC) power supplies, multiple output controllers designed for XScale processors, and 3-terminal regulators. Ultra-small, high-efficiency PMICs that are ideal for a wide range of consumer, industrial and networking devices including smartphones, tablet computers, solid-state drives, and networking and wireless IoT devices, as well as application specific power management ICs (PMICs) for a wide range of automotive, consumer, industrial, and networking applications including automotive TFT displays and ultrabooks, notebooks and tablet computers are also available. And, ICs for wireless charging that are suitable for the wearable market are included in Renesas' PMIC product offerings.
More Renesas' General Purpose power management ICs (PMIC chip) Part number:
| Part Number |
Description |
Topology [Rail 1] |
Outputs (#) |
Phases (Max) |
Control Type |
| ISL91211A |
Triple Output Power Management IC |
Buck |
3 |
2 |
Current Mode |
| ISL91211AIK |
Triple Output Power Management IC for Industrial and Computing Applications |
Buck |
3 |
2 |
Current Mode |
| ISL91211B |
Quad Output Power Management IC |
Buck |
4 |
1 |
Current Mode |
| ISL91211BIK |
Quad Output Power Management IC for Industrial and Computing Applications |
Buck |
4 |
1 |
Current Mode |
| ISL91212A |
Triple Output PMIC with I²C Interface |
Buck |
4 |
2 |
Current Mode |
| ISL91212B |
Quad Output PMIC with I²C Interface |
Buck |
4 |
1 |
Current Mode |
| ISL91301A |
Triple Output Power Management IC |
Buck |
3 |
2 |
Current Mode |
| ISL91301B |
Quad Output Power Management IC |
Buck |
4 |
1 |
Current Mode |
| ISL91302B |
Dual/Single Output Power Management IC |
Buck |
2 |
4 |
Current Mode |
| ISL91302BIK |
Dual/Single Output PMIC with 12-Bit Telemetry ADC |
Buck |
2 |
4 |
Current Mode |
| ISL9305 |
3MHz Dual Step-Down Converters and Dual Low-Input LDOs with I2C Compatible Interface |
|
4 |
1 |
Current Mode |
| ISL9305H |
3MHz Dual 1.5A Step-Down Converters and Dual Low-Input LDOs with I2C Compatible Interface |
|
|
|
|
| ISL9307 |
3MHz Dual 1500mA Step-Down Converters and Dual Low-Input LDOs |
Buck |
4 |
1 |
Current Mode |
Renesas Electronics Corporation delivers trusted embedded design innovation with complete semiconductor solutions that enable billions of connected, intelligent devices to enhance the way people work and live—securely and safely. A global leader in microcontrollers, analog, power, and SoC products and integrated platforms, Renesas provides the expertise, quality, and comprehensive solutions for a broad range of Automotive, Industrial, Home Electronics, Office Automation and Information Communication Technology applications to help shape a limitless future.
Category:
Capacitors
Development Boards, Kits, Programmers
Isolators
Power Supplies - Board Mount
Circuit Protection
Discrete Semiconductor Products
Kits
RF/IF and RFID
Crystals, Oscillators, Resonators
Integrated Circuits (ICs)
Memory Cards, Modules
Sensors, Transducers
Environmental & Export Classifications
| ATTRIBUTE |
DESCRIPTION |
| RoHS Status |
ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) |
3 (168 Hours) |
| REACH Status |
REACH Unaffected |
| ECCN |
3A991B1A |
| HTSUS |
8542.32.0071 |
