SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86 Integrated Circuits
SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86 Integrated Circuits SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86 Integrated Circuits

SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86 Integrated Circuits

Product Details:
Place of Origin: Malaysia
Brand Name: Texas Instruments
Certification: ROHS
Model Number: SN74HCS86QDRQ1
Payment & Shipping Terms:
Minimum Order Quantity: 10pieces
Price: Negotiated
Packaging Details: Tube
Delivery Time: 5 working days
Payment Terms: T/T, Western Union
Supply Ability: 50000PCS
Contact Now

Detail Information
Features: Schmitt Trigger Input Category: Electronic Components-Integrated Circuits(IC)
Series: Logic - Gates And Inverters Details: XOR (Exclusive OR) IC 4 Channel Schmitt Trigger Input
Mounting Type: Surface Mounting Description: IC GATE XOR 4CH 2IN 14SOIC
Package: 14-SOIC Base Part Number: 74HCS86
Operating Ambient Temperature Range: -40°C ~ 125°C (TJ) Applications: Automotive And Industrial Supplies,General Purpose,Step-Down CCCV Power Supplies
High Light:

IC 4 Channel

,

Schmitt Trigger Input Integrated Circuits

Product Description

SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86



XOR (Exclusive OR) IC 4 Channel Schmitt Trigger Input 14-SOIC Specification :

Logic Type
XOR (Exclusive OR)
Number of Circuits
4
Number of Inputs
2
Features
Schmitt Trigger Input
Voltage - Supply
2V ~ 6V
Current - Quiescent (Max)
2 µA
Current - Output High, Low
7.8mA, 7.8mA
Logic Level - Low
1V ~ 3V
Logic Level - High
1.5V ~ 4.2V
Max Propagation Delay @ V, Max CL
12ns @ 6V, 50pF
Operating Temperature
-40°C ~ 125°C (TA)
Mounting Type
Surface Mount
Supplier Device Package
14-SOIC
Package / Case
14-SOIC (0.154", 3.90mm Width)
Base Product Number
74HSC86







Images:

SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86 Integrated Circuits 0SN74HCS86QDRQ1 IC 4 Channel Schmitt Trigger Input 14-SOIC 74HCS86 Integrated Circuits 1
