DsPIC33FJ64MC508A 16 Bit Digital Signal Controllers IC Integrated Circuit

Microcontroller IC
Payment Method:
T/T, Western Union,PAYPAL
DsPIC33FJ64MC508A Motor Control 16-bit Digital Signal Controller IC
Electronic Components-Integrated Circuits(IC)
Mounting Type:
Surface Mounting
High-Performance, 16-bit Digital Signal Controllers
Base Part Number:
Operating Ambient Temperature Range:
-40°C ~ 85°C (TA)
High Light:

16Bit Digital Signal Controllers IC


DsPIC33FJ64MC508A Microcontroller IC


Digital Signal Controllers IC Integrated Circuit


dsPIC33FJ64MC508A High-Performance 16-bit Digital Signal Controllers IC integrated circuit

Analog Features:

• 12-bit Analog-to-Digital Converter (ADC) with: - 200 Ksps conversion rate - Up to 16 input channels - Conversion available during Sleep and Idle • Programmable Low-Voltage Detection (PLVD)
• Programmable Brown-out Reset Special

Microcontroller Features:
• Enhanced Flash program memory: - 10,000 erase/write cycle (min.) for industrial temperature range, 100K (typical)
• Data EEPROM memory: - 100,000 erase/write cycle (min.) for industrial temperature range, 1M (typical)
• Self-reprogrammable under software control
• Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
• Flexible Watchdog Timer (WDT) with on-chip low-power RC oscillator for reliable operation
• Fail-Safe Clock Monitor operation: - Detects clock failure and switches to on-chip low-power RC oscillator
• Programmable code protection
• In-Circuit Serial Programming™ (ICSP™)
• Selectable Power Management modes: - Sleep, Idle and Alternate Clock modes


dsPIC30F Motor Control 16-bit Digital Signal Controller.

Seamless migration options from this device to dsPIC33F and PIC24 devices in similar packages.



Interface - Drivers, Receivers, Transceivers
Microchip Technology

Digital Signal Controllers IC-MCU

Part Status
Architecture 16
MaxSpeed (MHz) 120
Program Memory Size (KB) 132
Multiple Flash Panels False
Temp. Range Min. -40
Temp. Range Max. 125
Operation Voltage Min.(V) 2.5
Operation Voltage Max.(V) 5.5
Pin Count 64
Low Power No
Number of Comparators 0
Number of ADCs 1
ADC Channels 16
Max ADC Resolution (bits) 12
Max ADC Sampling Rate (ksps) 200
Number of DACs 0
DAC outputs 0
Max DAC Resolution (bits) 0
Hardware RTCC No
Motor Control PWM Channels 0
SMPS PWM Channels 0
Number of PWM Time Bases 1
Output Compare Channels 8
USB Interface None
Number of CAN Modules 2
Type of CAN module CAN
Crypto Engine No
Quadrature Encoder Interface (QEI) 0
Segment LCD 0
LCD/Graphics Interface No
Configurable Logic Cell Modules (CLC /CCL) 0
Peripheral Pin Select (PPS)/Pin Muxing No



Peripheral Features:
• High-current sink/source I/O pins: 25 mA/25 mA
• Five 16-bit timers/counters; optionally pair up 16-bit timers into 32-bit timer module
• 16-bit Capture input functions
• 16-bit Compare/PWM
output functions: • Data Converter Interface (DCI) supports common audio Codec protocols, including I2S and AC’97
• 3-wire SPI modules (supports four Frame modes)
• I2C™ module supports Multi-Master/Slave mode and 7-bit/10-bit addressing
• Two addressable UART modules with FIFO buffers
• Two CAN bus modules compliant with CAN 2.0B standard
High-Performance Modified RISC CPU:
• Modified Harvard architecture
• C compiler optimized instruction set architecture
• Flexible addressing modes
• 83 base instructions
• 24-bit wide instructions, 16-bit wide data path
• Up to 144 Kbytes on-chip Flash program space • Up to 48K instruction words
• Up to 8 Kbytes of on-chip data RAM
• Up to 4 Kbytes of nonvolatile data EEPROM
• 16 x 16-bit working register array
• Up to 30 MIPS operation: - DC to 40 MHz external clock input - 4 MHz-10 MHz oscillator input with PLL active (4x, 8x, 16x)
• Up to 41 interrupt sources: - Eight user-selectable priority levels - Five external interrupt sources - Four processor traps
DSP Features:
• Dual data fetch
• Modulo and Bit-Reversed modes
• Two 40-bit wide accumulators with optional saturation logic
• 17-bit x 17-bit single-cycle hardware fractional/ integer multiplier
• All DSP instructions are single cycle: - Multiply-Accumulate (MAC) operation
• Single-cycle ±16 shift


Environmental & Export Classifications

RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
HTSUS 8542.32.0071
